COB LED Poster HD LED Display with Front Service Pixel Failure

Brand Name : TBCLED

Model Number : P1.56mm,P1.875

Certification : FCC，CE，ROHS

Place of Origin : China

MOQ : 10sqm

Price : Negotiable

Payment Terms : D/A

Supply Ability : 10000sqm/month

Delivery Time : 15days

Packaging Details : Flight Case

Adervantege : Top COB protechtion

Service : Front Service

Pixel Failure : <0.0003

Contrast Ratio : 1000:1

Ip Grade : IP31

Service Access : Back maintenance

Type : Fine Pixel Pitch LED Display

Max Power Consumption : 600W/sqm

Colours : 281 trillion

Contact Now

COB LED Poster: High-Definition Indoor Advertising with Smart Agility
Introducing our COB LED Poster—a breakthrough in indoor advertising that merges Flip Chip on Board technology with smart content management. This display delivers ultra-high definition, real-time promotion capabilities, and eco-friendly operation, making it a must-have for modern brands.
Core Strengths
  • Visual Superiority: With COB technology, the display offers minimal moire effect, high contrast, and cinema-quality imagery—perfect for content captured by cameras or designed for visual impact.
  • Timely Promotion Mastery: Update content instantly via WiFi, USB, or cloud control. Whether it's a last-minute sale or a time-sensitive announcement, your message stays fresh and relevant.
  • Sustainable Performance: LED technology reduces power consumption to an average of 100W per screen, with a lifespan of 100,000 hours—lowering operational costs and environmental impact.
Technical Specifications
Physical Parameters
Parameter P1.25 P1.56 P1.875
Pixel Pitch (mm) P1.25 P1.56 P1.875
Screen Size (mm) 600*1687.5 600*1687.5 600*2025
Configuration (WxH, per screen) 480*1350 pixels 384*1080 pixels 320*1080 pixels
No. of Cabinets (WxH, per screen) 5 5 6
Weight (per screen) 25kg 25kg 30kg
LED Type Flip-chip COB LED
Optical Parameters
Brightness (Max.) 600nits
Contrast Ratio 10,000:1
Viewing Angle - Horizontal/Vertical 170°/155°
Bit Depth 16 bit (internal processing 22bit)
Color Temperature - Adjustable 2,800K~10,000K
Electrical Parameters
Input Power Range 100~240VAC, 50/60Hz
Power Distribution (Max.) 320(W/Screen)
Power Distribution (Avg.) 100(W/Screen)
Resolution 3,840 Hz
Operational Parameters
Working Temperature / Humidity 0°C-+40°C/10%-80%RH
Storage Temperature / Humidity -20°C~+45°C/5%-95%RH
LED Lifetime 100,000 hours
Controller Built-in
Key Features
  • Maintenance Method: Front service design for easy access and repairs
  • Interface: Multiple expansion ports including USB, HDMI, audio, and more
  • Control Modes: Sync play, async play, USB, WiFi, and cluster cloud play for flexible content management
  • Installation Options: Multiple mounting configurations including floor, wall, hanging, and wheeled bases to suit any space requirement
COB LED Poster HD LED Display with Front Service Pixel Failure COB LED Poster HD LED Display with Front Service Pixel Failure COB LED Poster HD LED Display with Front Service Pixel Failure COB LED Poster HD LED Display with Front Service Pixel Failure COB LED Poster HD LED Display with Front Service Pixel Failure
Industry Applications
  • Retail Stores: Highlight products, promotions, and customer testimonials with engaging, high-definition content
  • Indoor Events: Promote schedules, speakers, or sponsors at conferences and exhibitions
  • Healthcare Facilities: Share health tips, service updates, or wayfinding information in clinics and hospitals
COB LED Poster HD LED Display with Front Service Pixel Failure

COB LED Poster HD LED Display with Front Service Pixel Failure

COB LED Poster HD LED Display with Front Service Pixel Failure
